Free shipping Pulse type Coin acceptor to PC RS232 interface

$20.00

Payments by PayPal
Always Free Shipping

Pulse type Coin acceptor to PC interface ( PULSE-RS232)

The WF-700-RELAY is an pulse to RS232 interface module for most models of coin acceptor products. The WF-700-RELAY has a built-in true RS232 port on its uplink communication port to interface with the serial port on a PC and a downlink port with inhibit line to interface with validators.
(This link is for WF-700-RELAY , if you want to order the USB type,please check another link for WF-700USB)

Package including:

1pcs WF-700-RELAY control board

1pcs wire to connect the coin acceptor to WF-700-RELAY Board

(This order link doesn't include any coin acceptor or bill acceptor)

About free shipping information:

We will ship through Post Air Mail parcel from China
If you place the order together 3 set in one time,we will send through the express delivery for you.

WF-700-RELAY


The WF-700-RELAY or WF-700USB is an pulse to interface module for most models of coin acceptor products. The WF-700-RELAY has a built-in true RS232 port on its uplink communication port to interface with the serial port on a PC and a downlink port with inhibit line to interface with validators.

WF-700,WF-700B are all updated to WF-700-RELAY or WF-700USB !!!

( For MDB type Coin validator and bill acceptor to PC, please check:MDB-PC adapter )

1.0 Introduction
The WF-700-RELAY is an RS232 interface module for most models of coin acceptor products. The WF-700-RELAY has a built-in true RS232 port on its uplink communication port to interface with the serial port on a PC and a downlink port with inhibit line to interface with validators.
With the WF-700-RELAY, the end operator can treat all different kinds of validators as a standard RS232 device and can concentrate on the real operation of the validator rather than the tedious interface work of the hardware discrepancy. On the PC platform, the software developer can easily program the validators via the WF-700-RELAY with common computer languages such as Visual Basic / C++.


2.0 Compatibility
WF-700-RELAY / WF-700USB is a successor of the WF-700 model. WF-700-RELAY is 100% functionality compatible to WF-700. With the DIP Switch, a more versatile configuration can be setup to interface with over 90% of the most commonly used banknote / coin validators found in the market.

3.0 Communications
This interface is a three wire interface using a Transmit line (TXD), a receive line (RXD) and a Common line. The Host machine is thought of as being the Master device. The WF-700-RELAY / WF-700USB is the slave device that responds only to the polls (or requests) from the Master.
In this polled system, the Master requests information from the WF-700-RELAY at a periodic rate. This rate can be as fast as every 30 milliseconds or as slow as the elapse time defined by the Lockout Timer. Faster rates are more desirable since overall system performance (in terms of bills/coins per minute accepted) will be higher at high poll rate system.
WF-700-RELAY has a “Lockout” Timer feature that it will disable the acceptor if the specified poll rate is not met. In another words, if the host system is too busy to keep up with the desired minimum poll rate, WF-700-RELAY will put the acceptor into the Disabled mode. The acceptor will be enabled again once the communication resumes.


Baud rate

Start bit

Data bits

Parity

Stop bit

9600 BPS

1

8

NO

1

Hardware Specification.


Power

Cable

Dimensions

Weight

12 VDC
Consumes an idle current  < 0.05A
0.5A for 1 sec. when accepting coins

Standard computer serial cable

approx. 75 x 65 x 30 mm

approx. 115 g



Add to Cart:

  • Model: WF-700-RELAY
  • Shipping Weight: 0.5g
  • 98 Units in Stock
  • Manufactured by: Wafer Microelectronics Co.,Ltd.


This product was added to our catalog on Wednesday 14 August, 2013.
