Specification:

Model name: GSM-RELAY V2016

Output: Seven relay output channel.

Output Rating: Maximum 10A /220V output channel

Power input:AC/DC12V-24V power input

Working frequency: GSM Quad band

Cover material: ABS water proof box

Weight: 0.6kg

Backup battery on board for power off alarm

Order Package(3sets) including:

3pcs GSM-RELAY Controller box (2016 new version)

3pcs GSM magnetic mount antenna (3 meter length wire)

3pcs WAFER USB program adapter board with cable

3pcs backup rechargeable battery inside the package

Package weight: 1.8 kg

GSM-RELAY GSM SMS Remote Control System ( Relay Switch Controller )

New version 2016 GSM relay controller, more features including:

Log data memeory for PC software to read
fast program and reset button on board
Support customized SMS controller for ON/OFF controller and pulse control each seperate relay channels)
On board backup battery for power off alarm

Same quality, better functions and more features!

The GSM-RELAY is a wireless gsm SMS remote control switch that connects to the GSM cell phone network.

It has seven independent relay switches, and the NO.1 Relay switch is activated by calling its cell phone number, it will reject the call without answering and switch on the device connected to it,then there are no call costs incurred when dialling the unit, it will recognise an authorised telephone number calling it and reject the call without answering.
It has other 6 independent relay switches which can be switched on or off by sending the GSM-RELAY an sms text message to control.

Specifications:

Real-time & interactive control
7 channels 250V 10A 50 Hz relay contacts
Works with GSM phones
Operating temperature (-25 .. +60 °C)
Relays operates almost every appliance
Small standby power (< 10mA 12V)
Relay memory after power failure
Optional password to keep the system at safety operating mode.
Remote Password change
Two operating mode optional ( remote setting with GSM phones)
One relay is woking with the phone calling, and others working with the SMS
Commands can added to GSM-phone number for raeady made commands
Working voltage is at 12~24V AC /DC.
On board backup battery for power off alarm

Applications:

Applications include the remote control of heating in holiday homes, lighting, engine pre-heaters, aviation engine heaters, irrigation systems, water well pumps, pumping stations, cabin heaters, resetting of remote servers, arming and disarming security systems, access control of gates and garage doors.

For android app,please go to google Play Store to search "GSM RELAY"

GSM-RELAY app software on the mobile phone for android and iphone system.

Go to google play store or Iphone app store to search "GSM RELAY"
